| CPU
 |
Intel Core i3, i5, i7 mobile processors
            Socket G2 (rPGA988B), Includes CPU Heatsink / fan for <35W processors
 |
|
Chipset / Video
 |
Intel HM67 Express Chipset
            Intel HD Graphics ( requires compatible CPU with built-in GPU )
 |
|
Memory
 |
2 * SODIMMs Sockets for un-buffered dual channel DDR3-1333/1066 up to 16 GB
 |
|
Expansion Slots
 |
1 * PCI Express x16 2.0 (by 16-lane) slot
            1 * PCI Express Mini Card slot
 |
|
Storage
 |
2 * Serial ATA III 6Gb/s & 3 * Serial ATA II 3Gb/s connectors
            Support RAID 0,1,5,10
 |
|
Audio
 |
VIA VT 1705 6-Channel HD Audio
 |
|
Ethernet LAN
 |
Intel 82577LM Gigabit Ethernet LAN
 |
|
LVDS
 |
Onboard 24-bit dual channel LVDS connector
 |
|
USB
 |
Embedded 2 * USB 3.0 & 8 * USB 2.0/1.1
 |
|
Special Features
 |
Supports ACPI S3, CPU Smart FAN, All solid capacitors
            Watchdog hardware monitor
 |
|
Rear Panel I / O
 |
2 * USB 3.0 & 4 * USB 2.0/1.1 ports
            1 * PS/2 KB/mouse combo connector
            1 * RJ-45 port
            1 * HDMI port & 1 * VGA port & 1 * DVI-D port
            1 * Audio port (Line-in, MIC and Line-out)
            1 * Coaxial Out & 1 * Optical Out
 |
|
Internal I / O
 |
2 * USB 2.0/1.1 headers for 4 USB ports
            1 * 24-bit dual channel LVDS header
            1 * Serial header ( RS232/422/485 )
            1 * GPIO header
            1 * Audio header, 1 * Front panel header
            1 * 24-pin ATX power connector, 1 * 4-pin 12V ATX power connector
 |
|
BIOS
 |
AMI EFI 32MB SMT Flash ROM
 |
|
Certificate
 |
CE, FCC, RoHS, EuP
 |
|
Functional
 |
ATM, Automation, medical Equipment, Security, Digital Signage, POS, General Application, Gaming Machine, Transportation
 |
|
Temperature
 |
Operating within 0~60 centigrade
            Storage within -20-85 centigrade
 |
|
Form Factor
 |
Mini-ITX Form Factor (170mm x 170mm) |
